KT-V12L Kunteng Dual hall 12 poles, 12 magnets pedal assisting sensor

KT-V12L Kunteng Dual hall 12 poles, 12 magnets pedal assisting sensor for ebike; it is easy to install on left side of the BB.

Cable length: 80cm

Cable connection:

Brown wire ---> +5v

Black wire---> Negative Electrode

Yellow wire ---> Signal

Note: This PAS only work with KT controller. Also,Kunteng controller normally set C1 = 2 as a defaullt setting for the 8 pole PAS, if you want to use 12 poles PAS, please set C1 =6 via the display, otherwise the PAS may not work.
