180W LiFePO4/Li-ion/lithium battery/lead acid battery charger

180W alloy shell charger

1. Power 180W

2. Charging current: 12V8A, 24V5A, 36V4A, 48V3A

3. Suitable for LiFePO4, Li-ion and lead acid battery

4. The charger will cutoff automatically after fully charged.

5. Overcharge protection

6. Overcurrent protection

7. Short circuit protection

8. Effeciency: ≥90%

9. Working temperature: -10℃~+40℃

10. AC cable length: 1.5m

11. DC cable length: 1m

How to calculate charging voltage for battery? Normally single cell charging voltage for li-ion is 4.2V, and single cell charging voltage for LiFePO4 is 3.65V; Single cell(12V) charging voltage for lead acid battery is 14.7V, therefore charging voltages for batteries are as follows:

24V LiFePO4 battery (8 cells in series): 8x3.65V=29.2V;

24V Li-ion battery (7 cells in series): 7x4.2V=29.4V;

24V Lead acid battery (2 cells in series): 2x14.7V=29.4V

36V LiFePO4 battery (12 cells in series): 12x3.65v=43.8V

36V Li-ion battery (10 cells in series): 10x4.2v=42V

36V Lead acid(3 cells in series): 3x14.7v=44.1V

48V LiFePO4 battery (16 cells in series): 16x3.65v=58.4V

48V Li-ion battery (13 cells in series): 13x4.2v=54.6V

48V Lead acid battery (4 cells in series): 4x14.7v=58.8V

60V Lead acid battery  (5 cells in series): 5x14.7v=73.5V

If your battery is different voltage, please inform us. Or if your battery is with different cells number in series, you can calculate the charging voltage yourself.

The lead time for the charger is about 2-5 days because different customers have different demand for the charging voltage and we need a few days to set and test before shipping.
